The JayBird Rx2T is a fast, high performance, two-place, aerobatic sport airplane. As with all airplanes designed by McMullan Aircraft Design, the airplane is designed for big, tall pilots. Pilots and passengers up to 6' 4" tall and baggage fit comfortably into the 45 inch wide cockpit. The airplane will accommodate engines from 150 to 230 horsepower but was designed exclusively for the time tested and proven Ford 3.8 liter V-6. The Douglas Fir and Birch plywood fuselage offers great safety and strength to the airframe. The JayBird Rx2T uses the same fuselage and engine as the JayBird Rx2 but uses a tapered wing and taildragger landing configuration for faster cruise speed and better climb performance.

Construction Materials

‚ Wood is still one of the best materials for building an airplane. It is easy to work with and only needs inexpensive tools to work with. For this reason the JayBird is built with clear vertical grain Douglas Fir and Birch aircraft grade plywood.

‚ Spring aluminum main gear


Calculated PerformanceSpecifications

Calculations are based on the Ford 3.8 Liter V-6 engine, rated at 180 hp, with prop speed reduction unit. Calculations are computer based and may vary with each individual aircraft.

WingSpan

28 ft

Range

700 miles

Wing Area

111 ft2

Takeoff Distance

N/A

Length

21' 10"

Landing Distance

N/A

Maximum Gross Weight 1700 lbs VMAX

240 mph

Empty Weight

800 lbs

VCR

220 mph

Payload (Full Fuel)

720 lbs

VS1

Stall Clean

63 mph

Fuel Capacity

30 gallons

VS0

Landing Config

45 mph

Seats

2

Climb Rate @ MSL

2400 fpm

Cabin Width

45"

Service Ceiling

20,000+
